Code: TF222-032-01
The Ajax GlandBox is a dedicated wiring accessory designed to provide clean, professional lateral cable entry for compatible Ajax EN54 fire system control equipment.
Ideal for installations where concealed cable routing is not possible, including retrofit projects, historic properties, and temporary commercial environments, the GlandBox enables tidy external cable management while maintaining a neat and professional system appearance. It integrates seamlessly with the Ajax EN54 Fire Hub Jeweller enclosure to deliver a consistent installation finish.
Developed with installer convenience in mind, the enclosure features multiple cable gland entry points, integrated alignment guides, and secure cable routing support to simplify fitting and improve cable organisation during installation.
Wiring accessory for Ajax EN54 control and indicating equipment
Designed for Ajax EN54 Fire Hub Jeweller
Neat lateral cable entry solution
Ideal for retrofit and surface cable routing installations
16 cable gland positions
Four gland positions on each side
Supports cable glands up to 20mm diameter
Built-in bubble level for easier installation
UP direction marker for alignment
Centre marking for accurate positioning
Latches for mounting panel fixing
Tamper button support for removal detection
Secure cable routing with fastener support
Compact low-profile design
Professional installation finish
Specification | Details |
|---|---|
Product Type | Wiring accessory / gland box |
Compatibility | Ajax EN54 Fire Hub Jeweller |
Cable Entry Positions | 16 |
Maximum Cable Gland Diameter | 20mm |
Dimensions | 263 x 223 x 40mm |
Weight | 335g |
Operating Temperature | +10°C to +40°C |
Operating Humidity | Up to 75% non-condensing |
IP Rating | IP20 |
Flammability Rating | UL 94 V-0 |
Colour Options | Black, White |
